PNEUMATIC ACTUATOR OPERATED 2 WAY WAFER FLUSH BOTTOM BALL VALVE F/E

Aline Pneumatic Operated Flush Bottom Valve is specially designed for complete and residue-free discharge of liquids, slurries, viscous media, and process fluids from reactors, vessels, storage tanks, and process equipment. Equipped with a high-performance pneumatic actuator, the valve provides fast, reliable, and automated operation while ensuring zero dead space and maximum product recovery.

The flush bottom design eliminates material accumulation at the tank bottom, reducing contamination risks and improving process efficiency. Its robust construction and leak-proof sealing make it ideal for demanding applications in chemical, pharmaceutical, and process industries.

Key Features:
• Pneumatic Actuated ON/OFF Operation
• Flush Bottom Design for Complete Drainage
• Zero Dead Space Construction
• Flanged End Connection
• Leak-Proof and Bubble Tight Shut-Off
• Low Maintenance Requirement
• Corrosion Resistant Construction
• Suitable for Automated Process Control
• Long Service Life
• Easy Installation and Operation

Technical Specifications:
• Valve Type: Flush Bottom Valve
• Operation: Pneumatic Actuated
• End Connection: Flanged End
• Actuator Type: Double Acting / Single Acting
• Size Range: 25 NB to 200 NB
• Body Material: WCB / SS304 / SS316 / SS316L
• Seat Material: PTFE / Metal Seated
• Pressure Rating: PN10 / PN16 / ANSI 150#
• Working Temperature: Up to 250°C (Depending on Material & Seat Selection)

Applications:
Chemical Reactors, Pharmaceutical Plants, Biotech Industries, Food & Beverage Processing, Paint & Coating Industries, Petrochemical Plants, Dye Manufacturing Units, Storage Tanks, Pressure Vessels, and Process Equipment Drainage Systems.
